SPECIFICATION
MATERIAL:
HOUSING:HIGH TEMPERATURE THERMOPLASTIC UL94V-0
CONTACTA(B): COPPER ALLOY
SHELL: SUSMIDDLE PLATE: SUS
ELECTRICAL:
CURUENT RATAING: VBUS AND GND CONTACTS RATED AT 3A Max
VBUS AND GND CONTACTS RATED AT 0.5A MIN
0.9AMPS MAX.FOR ALL OTHER CONTACT. PARALLELED FOR A TOTAL OF 5A
INITIAL CONTACT RESISTANCE: 40 MEGOHMS MAX
DIEELECTRIC WTHSTANDING VOLTAGE: 100V AC MIN.
MECHANICAL CHARACTERISTICS:
MATING FORCE: 5~20N
UNMATING FORCE: 8-20N (INITIAL),6-20N (AFTER 10000 CYCLES)
FREQUENCE: 200+50 CYCLES /HOUR,10000 CYCLES;
OPERATING TEMPERATUR: -40℃~80℃
IR REFLOW: THE PEAK TVPERATURE ON THE BOARD SHALL BF
MAINTAINED FOR 10 SECONDS AT 268℃
