SPECIFICATION
MATERIAL :
HOUSING: HIGH TEMPEATURE THERMOPLASTIC UL94V-0
CONTACT: COPPER ALLOY SHELL: SUSLATCH: SUS
ELECTRICAL :
CURUENT RATAING: VBUS AND GND CONTACTS RATED AT ЗA MAX
VBUS AND GND CONTACTS RATED AT 0.5A MIN
0.9AMPS MAX.FOR ALL OTHER CONTACT.
PARALLELED FOR A TOTAL OF 5A;
INITIAL CONTACT RESISTANCE : 40 MILLIOHMS;
DIEELECTRIC WITHSTANDING VOLTAGE: 100V AC MIN:
MECHANICAL CHARACTERISTICS :
MATING FORCE: 5-20N;
UNMATING FORCE: 8-20N(INITIAL), 6-20N (AFTER 10000 CYCLES)
FREQUENCE: 200+50 CYCLES/HOUR,10000 CYCLES
OPERATING TEMPERATURE:40℃-80℃SALT FOG TEST: 52 HOURS
