ELECTRICAL PERFORMANCE: 1. CURRENT RATING:5.0A VOLTAGE RATING:20V 2.INSULATION RESISTANCE: 100MΩ MIN 3.DIELECTRIC WITHSTAND VOLTAGE,AC 100V FOR 1 MINUTE 4.LOW CONTACT RESISTANCE: INITIAL 40MΩ AFTER 50MΩ
MATERIAL SPECIFICATION 1.HOUSING:HIGH TEMPERATURE RESISTANT PLASTIC,UL94 V-0 2.CONTACTS:COPPER ALLOY 3.SHELL:STAINLESS STEEL 4.MID PLATE: STAINLESS STEEL
PLATING SPECIFICATION: 1.CONTACTS: Ni 50u” MIN. UNDER PLATED OVER ALL. Au PLATED ON THE FUNCTIONAL AREA OF CONTACT. (GOLD PLATING THICKNESS FOLLOW THE P/N) GOLD FLASH PLATING ON SOLDER AREA 2.FRONT SHELL: Ni 30u” MIN. UNDER PLATED OVER ALL.
