SPECIFICATION
MATERIAL:
HOUSING: LCP(UL94V-0)
ACTUATOR: LCP(UL94V-0)
TERMINAL: PHOSPHOR BRONZE
SOLDER PAD: PHOSPHOR BRONZE
PLATING:
TERMINAL:1u”~3u” GOLD FLASH(NICKEL BARRIER)
SOLDER PAD: TIN OVER NICKEL(LEAD FREE)
RATING:
OPERATING VOLTAGE: 50V
CURRENT RATING: 0.2A
OPERATING TEMPERATURE:-55℃ ~+109℃
| PNNO | DMA | DMB | DMC | DMD | PINNO, | DIMA | DMB | DMC | DMD | PN NO | DMA | DIMB | DMC | DMD |
| 4 | 1.5 | 257 | 8.4 | 4.65 | 24 | 11.5 | 12.57 | 18.4 | 4.65 | 44 | 12.5 | 13.57 | 19.4 | 4.65 |
| 5 | 200 | 3.07 | 8.9 | 4.65 | 25 | 12 | 13.07 | 18.9 | 465 | 45 | 13 | 14.07 | 19.9 | 4.65 |
| 6 | 250 | 3.57 | 940 | 4.65 | 26 | 12.5 | 13.57 | 19.4 | 465 | 46 | 13.5 | 14.57 | 20.4 | A65 |
| 7 | 300 | 407 | 990 | 4.65 | 27 | 13 | 14.07 | 19.9 | 4.65 | 47 | 14 | 15.07 | 20.9 | 4.65 |
| 8 | 3.5 | 4.57 | 1040 | 4.65 | 28 | 13.5 | 14.57 | 20.4 | 4.65 | 48 | 14.5 | 15.57 | 21.4 | 5.15 |
| 9 | 400 | 5.07 | 10.9 | 4.65 | 29 | 14 | 15.07 | 20.9 | 465 | 49 | 15 | 16.07 | 21.9 | 5.15 |
| 10 | 4.5 | 5.57 | 11.4 | 4.65 | 30 | 14.5 | 15.57 | 2140 | 5.15 | 50 | 15.5 | 16.57 | 22.4 | 5.15 |
| 11 | 500 | 6.07 | 11.9 | 4.65 | 31 | 15 | 16.07 | 21.9 | 5.15 | 51 | 16 | 17.07 | 22.9 | 5.15 |
| 12 | 5.5 | 6.57 | 1240 | 4.65 | 32 | 15.5 | 16.57 | 2240 | 5.15 | 52 | 16.5 | 17.57 | 23.4 | 5.15 |
| 13 | 6 | 7.07 | 1290 | 4.65 | 33 | 16 | 17.07 | 22.9 | 515 | 53 | 26 | 2707 | 3290 | 5.15 |
| 14 | 6.5 | 7.57 | 1340 | 4.65 | 34 | 16.5 | 17.57 | 23.4 | 5.15 | 54 | 26.5 | 27.57 | 33.4 | 5.15 |
| 15 | 7 | 8.07 | 13.9 | 4.65 | 17 | 18.07 | 23.9 | 5.15 | 56 | 27 | 28.07 | 3390 | 5.15 | |
| 16 | 750 | 857 | 1440 | A65 | 36 | 17.5 | 18.57 | 24.4 | 5.15 | 56 | 27.5 | 28.57 | 34.4 | 5.15 |
| 17 | 90 | 9.07 | 14.9 | 4.65 | 18 | 19.07 | 24.9 | 5.15 | 57 | 2800 | 29.07 | 34.9 | 5.15 | |
| 18 | 8.5 | 9.57 | 15.4 | 4.65 | 38 | 18.5 | 19.57 | 25.4 | 5.15 | 58 | 28.5 | 29.57 | 35.4 | 5.15 |
| 19 | 900 | 10.07 | 15.9 | 4.65 | 39 | 19 | 20.07 | 25.9 | 5.15 | 59 | 29 | 30.07 | 35.9 | 5.15 |
| 20 | 9.5 | 10.57 | 16.4 | 4.65 | 40 | 10.5 | 11.57 | 17.4 | 465 | 60 | 2950 | 30.57 | 36.4 | 5.15 |
| 21 | 10 | 11.07 | 16.9 | 4.65 | 41 | 11 | 12.07 | 17.9 | 465 | 61 | 30 | 31.07 | 36.9 | 5.15 |
| 22 | 10.5 | 11.57 | 1740 | 4.65 | 42 | 11.5 | 12.57 | 18.4 | 465 | 62 | 30.5 | 31.57 | 37.4 | 5.15 |
| 23 | 11 | 1207 | 1790 | 4.65 | 43 | 12 | 13.07 | 1890 | 4.65 | 63 | 31 | 3207 | 3790 | 5.15 |
