SPECIFICATION
MATERIAL AND FINISH:
HOUSING AND COVER : LCP UL94V-ONATURE OR BLACK:
TERMINAL: PHOSPHOR COPPER AU/SN PLATED:
SOLDER: COPPER ALLOY AU/SN PLATED
TEMPERATURE RANGE: -40℃ ~+105℃
RATED VOLTAGE: 50V, AC/DC
CONTACT RESISTANCE: ≤40MΩ
INSULATION RESISTANCE:>500MΩ
WITHSTANDING VOLTAGE: 538V AC/MINUTE
